Built-in Fan Version
High Brightness Outdoor LCD Display 65 Inch Floor Standing for Retail Windows
Protection Grade:IP65 Brightness:2500nits Cooling system:Built-in Fan
Specifications
- SKU
- ZXTLCD-OUTV650O
High Brightness Outdoor LCD Display 65 Inch Floor Standing for Retail Windows
65 Inch Floor Standing Outdoor LCD Display for Retail-Facing Campaigns
A retail image that looks vivid inside a store can become difficult to see through glass or under strong daylight. Window reflections, exterior light and the customer’s viewing angle all affect how the campaign appears.
This 65 Inch Floor Standing Outdoor LCD Display uses a 2500-nit panel inside an IP65-rated cabinet with built-in fan cooling. The screen provides a large visual area for product launches, promotional images and customer information.
65-inch outdoor optical bonding digital signage with no fan | ||
|---|---|---|
Shell | IP rating | IP66 |
Material | Aluminium +SGCC galvanized steel sheet | |
Color | Black | |
Type | 5mm tempered high permeability glass | |
Light transmittance | 92% | |
IK rating | IK10 | |
LCD brand | LG | |
Backlight type | DLED | |
Display size | 1429*804mm | |
Display parameter | Display ratio | 16:9 |
Resolution | 3840*2160 | |
Brightness | 2500nits | |
Contrast ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Signal input | 3840*2160 | |
Port | USB*2 HDMI IN*1 | |
Language | Chinese/English | |
No fan | Superconducting aluminum sheet cooling | |
Work temperature | -20℃～70℃ | |
Storage temperature | -10℃～60℃ | |
Work environment | Working humidity | 10%～95% |
Store humidity | 5%～90% | |
Work environment | Sound | 0dB |
Input voltage | AC110-240V,50/60Hz | |
Rated power consumption | 320W | |
Motherboard | Android/Windows | |
Network mode | 4G/WIFI/RJ45 | |
Optional content | Touch | G+G capacitive touch |
VESA mounting holes，support wall mounting/floor,Horizontal and vertical screens are universal | | |
Machine size(H*W*D) | 1509*884*100mm | |
Net weight | 90kg | |
Package size and weight | Package material | Honeycomb Paper Box |
Package size H*W*D | 1020*1670*280mm | |
Package size and weight | Gross weight | 110kg |
Working With Storefront Reflections
High brightness gives the display a stronger starting point, but screen placement remains important. A display facing direct afternoon sunlight may behave differently from one installed under an entrance canopy.
The site survey should record sunlight direction, reflective glass and pedestrian approach routes. In some projects, changing the screen angle can improve visibility more effectively than increasing brightness alone.
Designing Retail Content for a 65-Inch Screen
Large product photographs are one of the main advantages of this format. Fashion, automotive, food and lifestyle campaigns can be presented with enough visual scale to attract customers from across an open commercial area.
A practical campaign may combine:
- One dominant product image
- A short benefit-led headline
- A clearly visible offer
- A store direction
- A single QR code or action
Too many small elements weaken the effect of the larger screen.
Protection for Exterior Commercial Use
The IP65 enclosure provides dust protection and resistance to water jets. Power and network entry points need to be sealed correctly during installation.
The built-in fan system assists with internal heat management during long retail operating hours. Maintenance clearance should be reserved even when the kiosk is positioned close to a storefront.
Operational Questions
Before selecting a 65 Inch Floor Standing Outdoor LCD Display, the retailer should establish who controls the content, how frequently campaigns change and whether different stores require different schedules.
Media-player type, remote management, power-on scheduling and nighttime brightness should be discussed before production rather than after installation.
The 65 Inch Floor Standing Outdoor LCD Display is suitable for retailers that need large promotional images and outdoor visibility while retaining the flexibility of a freestanding commercial cabinet.
