Built-in Fan Version
High Brightness Outdoor Advertising Display 55 Inch Floor Standing for Bus Station Wayfinding
Protection Grade:IP65 Brightness:2500nits Cooling system:Built-in Fan
Specifications
- SKU
- ZXTLCD-OUTFVPD550B
55 Inch Double Sided Outdoor Advertising Display for Open-Air Bus Stations
The product image shows a dark portrait display mounted within a light-colored freestanding lower cabinet. Its body is deeper than a typical single-screen digital poster because this product uses display faces on both sides.
The 55 Inch Double Sided Outdoor Advertising Display can communicate with passengers approaching from opposite directions at an outdoor bus station or roadside interchange.
Its listed specifications include 2500-nit brightness, IP65 protection and built-in fan cooling.
55 Inch Outdoor floor standing digital signage Built-in Fan for Ventilation | ||
|---|---|---|
The containment structure | The material and feature of shell | IP65 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
Panel Spec | Backlight type | ELED |
Display size( mm) | 1920*1080 | |
Display ratio | 16:9 | |
Resolution | 1920*1080 | |
Brightness | 1500cd/㎡ | |
Contrast Ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Touch Overlay for Interactivity(Optional) | Touch style | Projected Capacitive Touch screen |
Touch points | 10 points | |
Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
Built-in Android Media Player PCB Board Configuration | Processor Chip | RK3576, six core |
RAM | 4GB | |
Flash Memory Card | 32GB | |
Wifi and 4G | Yes | |
Version | Android 14.0 | |
Built-in PC Board Configuration(Optional) | CPU | Intel Core i5 Processor |
RAM | 8GB DDR4 | |
Storage | 128GB SSD | |
Operating System | Windows 10 / Windows 11 | |
Graphics | Integrated Intel UHD Graphics | |
Network | LAN + WiFi Wireless Network | |
Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
Audio format | MP3, WMA | |
Photo format | BMP, JPEG, PNG, GIF etx | |
Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
HDMI | 1 | |
USB | 2 | |
Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
Speakers | Dual side speakers for Audio | |
ECU | Switch power supply | Industrial Power supply |
Waterproof speaker | High quality waterproof 10W speaker | |
Thunder Preventer | The tree-level lightning protection | |
Leakage protective device | Defend Electricity Leakage | |
Timer | Set up on/off time on day/week/month | |
Outdoor OMC system（optional） | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
Problem and staus monitoring software included. | ||
Touble shooting by software included. | ||
Use softwae Remote Check key working performance by Group | ||
Unnormal work alarm generation | ||
Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
Environment | Working temperature | 0℃～+50℃(Optional heater installed up to -20℃～+50℃) |
Working humidity | 10%～90% | |
Working Voltage | AC110-240V,50/60Hz | |
Max Power Consumption | ≤850W | |
Mechanical Para | Machine seize H*W*D( mm) | 2100*890*300 |
Net weight(Kg) | 200 | |
Package size H*W*D( mm) | 1120*2500*570 | |
Gross weight(Kg) | 260 | |
Two Directions, Different Passenger Needs
Passengers entering a station need different information from those walking toward an exit. A double-sided unit allows content to reflect these different journeys.
One face may present:
- Routes and boarding directions
- Bay or platform numbers
- Temporary service changes
- Outdoor station maps
The reverse face may show:
- Exit directions
- Connections to parking
- Local-area information
- Outdoor advertising
- Directions to taxi or pickup zones
Operational and safety information should remain more prominent than commercial content.
A Balanced Outdoor Cabinet
The image shows a dark screen area contrasted against a broad white base. This gives the cabinet a grounded appearance while keeping visual attention on the content.
Because it is double-sided, installation drawings must include the complete cabinet depth. Benches, shelter panels and other station infrastructure should not block either face.
The unit must remain outside accessible paths and should not reduce the driver’s view of pedestrians.
Daylight and Nighttime Conditions
The 2500-nit output supports outdoor daylight viewing. The two faces may receive very different sunlight depending on orientation, so both sides should be evaluated separately.
A screen facing east may experience morning glare while the reverse face receives stronger afternoon sun. Content contrast and brightness control should account for this difference.
IP65 protection and fan cooling support outdoor operation. Road dust makes ventilation inspection particularly important.
A More Efficient Two-Way Information Point
Using one 55 Inch Double Sided Outdoor Advertising Display can reduce the need for two separate cabinets, foundations and power routes.
The benefit depends on the site genuinely having useful viewing traffic on both sides. It should not be selected solely because two screens appear more impressive.
