Built-in Fan Version
55 Inch Vertical Outdoor Advertising Kiosk for Bus Wayfinding
Protection Grade:IP65 Brightness:2500nits Cooling system:Built-in Fan
Specifications
- SKU
- ZXTLCD-OUTFVP550MG
55 Inch Vertical Outdoor Advertising Kiosk for Open-Air Bus Stations
The product image shows a light green vertical cabinet with a relatively narrow body and an integrated base. Its proportions make it appear less visually heavy than many large outdoor kiosks, which can be useful near pedestrian routes.
This 55 Inch Vertical Outdoor Advertising Kiosk is specified with 2500-nit brightness, IP65 protection and built-in fan cooling.
A Format for Outdoor Decision Points
The 55-inch screen can be positioned near an exterior station entrance, roadside platform, outdoor transfer point or pedestrian route leading to bus bays.
It is large enough for route directions and short service notices but more manageable than a 75- or 86-inch cabinet in areas with limited ground space.
The kiosk must not reduce wheelchair clearance or block drivers’ views of pedestrians.
55 Inch Outdoor floor standing digital signage Built-in Fan for Ventilation | ||
|---|---|---|
The containment structure | The material and feature of shell | IP65 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
Panel Spec | Backlight type | DLED |
Display size( mm) | 1210*681 | |
Display ratio | 16:9 | |
Resolution | 1920*1080 | |
Brightness | 2000-2500cd/㎡ | |
Contrast Ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Touch Overlay for Interactivity(Optional) | Touch style | Projected Capacitive Touch screen |
Touch points | 10 points | |
Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
Built-in Android Media Player PCB Board Configuration | Processor Chip | RK3576, six core |
RAM | 4GB | |
Flash Memory Card | 32GB | |
Wifi and 4G | Yes | |
Version | Android 14.0 | |
Built-in PC Board Configuration(Optional) | CPU | Intel Core i5 Processor |
RAM | 8GB DDR4 | |
Storage | 128GB SSD | |
Operating System | Windows 10 / Windows 11 | |
Graphics | Integrated Intel UHD Graphics | |
Network | LAN + WiFi Wireless Network | |
Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
Audio format | MP3, WMA | |
Photo format | BMP, JPEG, PNG, GIF etx | |
Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
HDMI | 1 | |
USB | 2 | |
Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
Speakers | Dual side speakers for Audio | |
ECU | Switch power supply | Industrial Power supply |
Waterproof speaker | High quality waterproof 10W speaker | |
Thunder Preventer | The tree-level lightning protection | |
Leakage protective device | Defend Electricity Leakage | |
Timer | Set up on/off time on day/week/month | |
Outdoor OMC system（optional） | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
Problem and staus monitoring software included. | ||
Touble shooting by software included. | ||
Use softwae Remote Check key working performance by Group | ||
Unnormal work alarm generation | ||
Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
Environment | Working temperature | 0℃～+50℃(Optional heater installed up to -20℃～+50℃) |
Working humidity | 10%～90% | |
Working Voltage | AC110-240V,50/60Hz | |
Max Power Consumption | ≤450W | |
Mechanical Para. | Machine seize H*W*D( mm) | 2000*840*150 |
Net weight(Kg) | 100 | |
Package size H*W*D( mm) | 1070*2150*470 | |
Gross weight(Kg) | 140 | |
Using the Light-Colored Enclosure
The light green sample shown in the image creates a softer appearance than a dark industrial cabinet. It may suit landscaped stations, tourism routes or a color-coded transport system.
Color should not be used as the only wayfinding method because some passengers may have difficulty distinguishing it. Route numbers, words and symbols must remain clear.
Final color availability and outdoor coating specifications require confirmation.
Wayfinding Content
A practical layout should prioritize:
- Destination or route
- Directional arrow
- Stop or bay number
- Walking distance
- Temporary change
Advertising can be shown when it does not obscure transport and safety information.
Outdoor Performance
The 2500-nit panel supports daylight visibility. Nighttime brightness and possible road glare should also be assessed.
IP65 protection helps defend the enclosure against dust and water jets. Built-in fan cooling assists with thermal management, while transport dust makes routine airflow inspection important.
The 55 Inch Vertical Outdoor Advertising Kiosk provides a balanced screen size and relatively narrow visual profile for outdoor passenger wayfinding.
