Built-in Fan Version
55 Inch Floor Standing Outdoor Digital Signage for Drive-Thru Menus
Protection Grade:IP65 Brightness:2500nits Cooling system:Built-in Fan
Specifications
- SKU
- ZXTLCD-OUTFVP550O-B
55 Inch Floor Standing Outdoor Digital Signage for Drive-Thru Menus
The product image shows a bright orange-red enclosure with a tall portrait screen and a continuous floor-standing body. The cabinet is visually more prominent than a standard black kiosk and could help identify a specific ordering point within an outdoor drive-thru lane.
This 55 Inch Floor Standing Outdoor Digital Signage model is listed with 2500-nit brightness, IP65 protection and built-in fan cooling.
55 Inch Outdoor floor standing digital signage Built-in Fan for Ventilation | ||
|---|---|---|
The containment structure | The material and feature of shell | IP65 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
Panel Spec | Backlight type | DLED |
Display size( mm) | 1210*681 | |
Display ratio | 16:9 | |
Resolution | 1920*1080 | |
Brightness | 2000-2500cd/㎡ | |
Contrast Ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Touch Overlay for Interactivity(Optional) | Touch style | Projected Capacitive Touch screen |
Touch points | 10 points | |
Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
Built-in Android Media Player PCB Board Configuration | Processor Chip | RK3576, six core |
RAM | 4GB | |
Flash Memory Card | 32GB | |
Wifi and 4G | Yes | |
Version | Android 14.0 | |
Built-in PC Board Configuration(Optional) | CPU | Intel Core i5 Processor |
RAM | 8GB DDR4 | |
Storage | 128GB SSD | |
Operating System | Windows 10 / Windows 11 | |
Graphics | Integrated Intel UHD Graphics | |
Network | LAN + WiFi Wireless Network | |
Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
Audio format | MP3, WMA | |
Photo format | BMP, JPEG, PNG, GIF etx | |
Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
HDMI | 1 | |
USB | 2 | |
Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
Speakers | Dual side speakers for Audio | |
ECU | Switch power supply | Industrial Power supply |
Waterproof speaker | High quality waterproof 10W speaker | |
Thunder Preventer | The tree-level lightning protection | |
Leakage protective device | Defend Electricity Leakage | |
Timer | Set up on/off time on day/week/month | |
Outdoor OMC system（optional） | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
Problem and staus monitoring software included. | ||
Touble shooting by software included. | ||
Use softwae Remote Check key working performance by Group | ||
Unnormal work alarm generation | ||
Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
Environment | Working temperature | 0℃～+50℃(Optional heater installed up to -20℃～+50℃) |
Working humidity | 10%～90% | |
Working Voltage | AC110-240V,50/60Hz | |
Max Power Consumption | ≤450W | |
Mechanical Para. | Machine seize H*W*D( mm) | 2000*840*150 |
Net weight(Kg) | 100 | |
Package size H*W*D( mm) | 1070*2150*470 | |
Gross weight(Kg) | 140 | |
A Compact Menu Position
A 55-inch display works well where drivers stop relatively close to the screen. It can show a focused menu, promotional products or a secondary confirmation message without requiring the physical scale of a 75-inch cabinet.
The bright enclosure shown in the image may be useful for branded restaurant locations, but it should not conflict with traffic-control signs or safety colors. The final finish must be confirmed before production.
Content for Drivers
The menu should be tested from the actual vehicle position. Important elements include:
- Large category headings
- Clearly separated prices
- High-contrast product photographs
- Short upgrade information
- One promotional message
Thin lettering and small multi-column lists should be avoided.
Weather and Traffic Exposure
The 2500-nit screen supports outdoor daylight viewing. Screen orientation should account for direct sunlight and windshield reflections.
IP65 protection helps protect the cabinet against dust and water jets. The installation needs sealed cable routes and suitable drainage around the base.
Built-in fan cooling assists during long operating hours. The cabinet should remain serviceable without closing all drive-thru traffic.
FAQ
Can the bright cabinet color be customized?
The image shows an orange-red sample. Other colors should only be promised after coating and customization options are confirmed.
Is 55 inches suitable for a complete restaurant menu?
It depends on menu length and viewing distance. Larger menus may need multiple screens or a larger display.
Can it change from breakfast to lunch automatically?
This requires a media player or CMS with scheduling capability.
The 55 Inch Floor Standing Outdoor Digital Signage model provides a compact outdoor menu position whose enclosure can also contribute to restaurant identification and branding.
