55 Inch Outdoor Digital Signage with 2500 Nits IP65 Wall Mounted Design for Drive Thru Menus
Network:WIFI / LAN / 3G / 4G Optional Resolution:1920*1080 / 3840*2160 Operating system:Android / Windows os Back:Cold-rolled sheet metal board
Specifications
- SKU
- ZXTLCD-OUTAHW550RB
55 Inch Wall Mounted Drive Thru Menu Board for Space-Limited Lanes
Some drive-thru lanes run directly beside the restaurant wall, leaving little room for a freestanding menu cabinet. A 55 Inch Wall Mounted Drive Thru Menu Board can use that existing exterior surface while keeping the lane edge clear.
The product image shows a light green horizontal enclosure suitable for landscape menu artwork.
55 Inch Outdoor horizontal wall-mounted display with air-cooling specification | ||
|---|---|---|
The containment structure | The material and feature of shell | IP65 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
Panel Spec | Backlight type | ELED |
Display size(mm) | 1210*680 | |
Display ratio | 16:9 | |
Resolution | 1920*1080 | |
Brightness | 1500cd/㎡ | |
Contrast Ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Touch Overlay for Interactivity(Optional) | Touch style | Projected Capacitive Touch screen |
Touch points | 10 points | |
Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
Built-in Android Media Player PCB Board Configuration | Processor Chip | RK3576, six core |
RAM | 4GB | |
Flash Memory Card | 32GB | |
Wifi and 4G | Yes | |
Version | Android 14.0 | |
Built-in PC Board Configuration(Optional) | CPU | Intel Core i5 Processor |
RAM | 8GB DDR4 | |
Storage | 128GB SSD | |
Operating System | Windows 10 / Windows 11 | |
Graphics | Integrated Intel UHD Graphics | |
Network | LAN + WiFi Wireless Network | |
Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
Audio format | MP3, WMA | |
Photo format | BMP, JPEG, PNG, GIF etx | |
Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
HDMI | 1 | |
USB | 2 | |
Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
Speakers | Dual side speakers for Audio | |
ECU | Switch power supply | Industrial Power supply |
Waterproof speaker | High quality waterproof 10W speaker | |
Thunder Preventer | The tree-level lightning protection | |
Leakage protective device | Defend Electricity Leakage | |
Timer | Set up on/off time on day/week/month | |
Outdoor OMC system（optional） | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
Problem and staus monitoring software included. | ||
Touble shooting by software included. | ||
Use softwae Remote Check key working performance by Group | ||
Unnormal work alarm generation | ||
Built-in Air conditioner for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust internal temperature |
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
Environment | Working temperature | 0℃～+50℃(Optional heater installed up to -20℃～+50℃) |
Working humidity | 10%～90% | |
Working Voltage | AC110-240V,50/60Hz | |
Max Power Consumption | ≤450W | |
Mechanical Para | Machine seize H*W*D(mm) | 1420*890*150 |
Net weight(Kg) | 85 | |
Package size H*W*D(mm) | 1160*1570*300 | |
Gross weight(Kg) | 115 | |
Design Around the Stopping Position
Wall mounting changes the viewing angle. The display may need a bracket that turns it slightly toward the driver rather than sitting flat against the building.
A site test should confirm:
- Distance from vehicle to wall
- Driver eye level
- Smallest readable price
- Sun reflection at meal times
- Clearance from windows and service doors
A Menu, Not a Television Advertisement
The 55 Inch Wall Mounted Drive Thru Menu Board should keep product names, prices and availability easy to locate. Promotional animation must not interfere with ordering.
Daypart scheduling can automatically change between breakfast, lunch and evening menus. Unavailable products can be removed without covering the screen with temporary printed notices.
Cooling and Cleaning
The backend identifies built-in air conditioning. IP65 protection and 2500-nit brightness support exterior restaurant operation.
Grease, dust and water marks can affect visible contrast. The 55 Inch Wall Mounted Drive Thru Menu Board needs routine glass cleaning as well as planned cooling-system maintenance.
If you would like to get the specification about above product, or you hope to discuss your requirements or need any additional information on our this product , then please do not hesitate to send us a inquiry and contact our sales team now.
